PLC Adjustment Rectangular 10 Ton Aluminium Melting Furnace

Brand Name:	Bolv
Model Number:	20T
MOQ:	1 set
Price:	USD 120,000
Packaging Details:	Standard export packaging (carbon box, pallet, film)
Payment Terms:	T/T,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Name:

Aluminum Scrap Melting Furnace

Tonnage:

10T

Maximum Scrap Loading:

22T

Burner Type:

Regenerative Burner

Fuel:

Natural Gas 8400kcal/m³

Melting Period Fuelconsumption:

65 M³ /ton Of Aluminum (continuous Working To Melt The Scrap To 710℃

Maximum Natrual Gas Consumption:

Maximum 350N M³/hour (quick Melting Period)

Burner Load Adjustment:

PLC Adjustment

Scrap Type:

Loose Or Baled Aluminum Scrap, UBC, Automobile Engine

Supply Ability:

20 sets/ year

Product Description

PLC Adjustment Rectangular 10 Ton Aluminium Melting Furnace

Product Overview

The 10-ton aluminum melting furnace is professionally developed to smelt high-quality aluminum alloy molten liquid, which serves as the core feeding material for downstream casting production equipment. It stably provides qualified molten aluminum to ensure the continuous and standardized operation of the subsequent casting process.

Operators can load proportioned aluminum ingots and recycled aluminum scraps into the furnace chamber through forklift handling or manual feeding methods. After the feeding process is completed, the regenerative combustion device is started to initiate the aluminum material melting operation. In the melting process, surface slag will float on the top layer of the molten liquid, while the effective alloy materials sink and gather at the bottom of the furnace.

When the temperature of the aluminum alloy molten liquid is close to the preset production standard, operators will perform initial component calibration and surface slag removal at the furnace mouth, and precisely adjust the molten liquid temperature to reach the qualified production range.

Subsequently, secondary precise component tuning, comprehensive slag cleaning and alloy refining treatments are implemented to further optimize the quality of the molten aluminum. Throughout the whole process, the intelligent combustion system automatically and stably controls the temperature of the molten liquid to avoid temperature fluctuation and ensure consistent product quality.

After passing quality inspection, the refined qualified aluminum alloy molten liquid can be output to the casting process for formal batch production.

Technical Parameters

Furnace Structure: Fixed rectangular furnace
Molten Aluminum Working Temperature: 720℃—760℃
Furnace Chamber Maximum Temperature: 1050℃—1100℃
Angle Between Furnace Bottom and Furnace Door: 30º
Aluminum Discharging Mode: Manual discharge outlet operation
Number of Discharge Taps: 1
Discharge Tap Diameter: Φ60
Number of Burners: 2
Burner Type: Regenerative combustion type
Applicable Fuel: Natural gas
Fuel Working Pressure: 0.15-0.2Mpa (based on manufacturer’s pipe network pressure standard)
Fuel Calorific Value: 8400Kpa / m³
Maximum Burner Air Consumption: 300 – 400m³/ h
Ignition Mode: Electric spark ignition for natural gas pilot burner
Flame Safety Protection: Equipped with ultraviolet detector, realizing automatic pilot burner flame monitoring and safety protection

Frequently Asked Questions

Q: What are the production capacities of furnaces with different tonnages?

A: The hourly melting capacity of the 20-ton aluminum melting furnace is 4 to 6 tons. The 25-ton and 45-ton upgraded models feature higher melting and production efficiency. All furnace models support 24-hour uninterrupted continuous operation, which can perfectly match the working rhythm of supporting casting production lines and meet large-scale continuous production demands.
