Trackless Wire Cable Winch Casting Machine

Brand Name:	Bolv
Model Number:	20T
MOQ:	1 set
Price:	USD 360,000
Packaging Details:	Standard export packaging (carbon box, pallet, film)

Detail Information

Product Description

Detail Information

Place of Origin:

China

Name:

Billet Casting Table

Lifting Speed:

30 To 800mm/min Infinitely Adjustable, With Manual Descent Device

Working Conditions:

Intermittent Start-up

Application:

Aluminum Ingot Or/ And Billet Casting, Aluminum Liquid Transfer

Rated Lifting Capacity:

5-60 Tons

Lifting Height:

4 To 12 Meters

Casting Size Range:

4-26 Inches

Supply Ability:

30 sets/ year

Highlight:

trackless wire cable winch

billet casting machine with warranty

cable winch casting equipment

Product Description

Trackless Wire Cable Winch Casting Machine

This industrial casting machine features a robust stainless steel wire angle structure designed for heavy-duty applications in demanding environments.

Complete Equipment Package

Angle devices including rollers, gear reducers, and wheel assemblies
Wire ropes and supporting components
Zinc components
Well supports
Tilting devices
Hydraulic cylinder assemblies
Hydraulic power plants
Electric control systems

Technical Specifications

Specification	Detail
Maximum Working Distance	>12 meters
Roller Configuration	Single roller matching four steel wires
Equipment Roll Material	Φ219 seamless steel pipe with 30mm weight thickness
Manufacturing Process	Mounting welding and precision machining
Steel Wire	Special polygonal steel wire, 100m length, Φ16mm
Fasteners	Stainless steel bolts for wire length adjustment
Maximum Load Capacity	18 tons under high water conditions
Motor Power	5.5 kW rated power
Reduction System	200mm sprocket reduction, 500mm gear reduction

Structural Components

The well closure frame is constructed from 250*100*10 square steel tubes and 25mm thick steel plates. The angle's four main wheel sets are integrated into a well runway frame, all designed with type 6210 double bearings for enhanced durability and performance.

Skanebase and skane arm components are securely fixed to the frame construction. A 5-inch water inlet is mounted on the well frame to facilitate cooling through the waterway system.
