Rail-Free Wire Rope Winch Casting Machine

Brand Name:	Bolv
Model Number:	20T
MOQ:	1 set
Price:	USD 360,000
Packaging Details:	Standard export packaging (carbon box, pallet, film)

Detail Information

Product Description

Detail Information

Place of Origin:

China

Name:

Billet Casting Table

Lifting Speed:

30 To 800mm/min Infinitely Adjustable, With Manual Descent Device

Working Conditions:

Intermittent Start-up

Application:

Aluminum Ingot Or/ And Billet Casting, Aluminum Liquid Transfer

Rated Lifting Capacity:

5-60 Tons

Lifting Height:

4 To 12 Meters

Casting Size Range:

4-26 Inches

Supply Ability:

30 sets/ year

Highlight:

rail-free wire rope winch

,

billet casting machine with winch

,

wire rope winch casting equipment

Product Description

Rail-Free Wire Rope Winch Casting Machine

Product Overview

This advanced casting machine features a rail-free steel wire rope winch structure designed for heavy-duty industrial applications. The complete system includes all necessary components for efficient operation.

Complete Supply Package

Winch unit with winding drum, speed reducer, and pulley sets
Steel wire ropes and supporting components
Sinking tank and wellhead support frame
Tilting device and hydraulic cylinder assembly
Hydraulic power unit and electrical control system

Technical Specifications

Specification	Details
Maximum Operating Stroke	Exceeds 12 meters
Winch Configuration	Single winding drum with four steel wire ropes
Drum Construction	Φ219 seamless steel pipes with 30mm wall thickness
Wire Rope Specifications	100-meter-long Φ16mm special multi-strand full steel core
Fastener Material	Stainless steel bolts for wire rope length adjustment
Maximum Load Capacity	18 tons under high water level conditions
Motor Rating	5.5kW
Reducer Specifications	200mm center distance (worm gear), 500mm center distance (gear)

Structural Components

Wellhead Frame: Fabricated from 250*100*10 square steel tubes and 25mm thick steel plates
Pulley System: Four main pulley groups integrated with dual-bearing design using 6210 model bearings
Tilting Mechanism: Base and arm assembly fixedly mounted on frame structure
Cooling System: 5-inch water inlet connector for cooling water access
