Hydraulic Internal Guide Billet Caster Machine 20 Tons Continuous Casting Machines

Brand Name:	Bolv
Model Number:	20T
MOQ:	1 set
Price:	USD 360,000
Packaging Details:	Standard export packaging (carbon box, pallet, film)

Detail Information

Product Description

Detail Information

Place of Origin:

China

Rated Lifting Capacity:

5-60 Tons

Lifting Height:

4 To 12 Meters

Casting Size Range:

4-26 Inches

Casting Shape:

Round, Rectangular

Control:

Application:

Aluminum Ingot Or/ And Billet Casting, Aluminum Liquid Transfer

Supply Ability:

30 sets/ year

Highlight:

Hydraulic Internal Guide Billet Caster Machine

Billet Caster Machine 20 Tons

20 Tons Continuous Casting Machines

Product Description

Hydraulic Internal Guide Billet Caster Machine 20 Tons Continuous Casting Machines

Product Overview

The Hydraulic Internal Guide Billet Casting Machine is a 20-ton continuous casting system designed for aluminum billet production, featuring advanced hydraulic technology and intelligent control systems.

Primarily used for casting aluminum billets with exceptional process stability
Internal guide oil cylinder design encloses all moving components, ensuring stable product quality and minimal maintenance requirements
Comparable running costs to traditional casting machines with superior product quality for high-end applications
Energy-efficient single-acting inner guide cylinder operation without power consumption during casting
Intelligent control system enables high automation levels and reduced personnel requirements

Technical Specifications

Max casting length	6800mm
Casting length tolerance	±0.5%
Max stroke of the hydraulic cylinder	7200mm
Casting speed	20 to 250 mm/min
Casting billet straightness	1mm/m, 4mm/6.8m
Casting table repeat positioning tolerance	± 1mm
Table horizontal tolerance	≤2 mm
Table vertical tolerance	≤1.5 mm
Tilting angle	0°-85°
Tilting repeat positioning tolerance	±1.0mm
Runner liquid level detection tolerance	Set data ±2mm
Cooling water flowage	150-650m³/h

Frequently Asked Questions

What are the core advantages of vertical hydraulic inner guide casting machine?

It features stable vertical operation, precise inner guide positioning, uniform metal liquid filling, low vibration, minimal casting defects, and high finished product yield.

How does the hydraulic inner guide structure improve casting quality?

The built-in inner guide design ensures straight billet forming, effectively prevents bending and deformation, controls casting size tolerance accurately, and improves surface finish quality.

Is this casting machine easy to maintain and operate?

The system adopts integrated hydraulic control with simple operation procedures, standardized lubrication, and wearing parts replacement design, resulting in low daily maintenance costs and extended service life.
